adafruit

WLED + ESP32-S3
+
Neopixels
= airborne poetry

Video coming out JULY 2, 2025!

#ledzeppelin #skyart #adafruit

Habr

Русская «Ардуина»: первый взгляд любителя

Я — самодельщик-ардуинщик со стажем. Люблю пихать ардуины во всякие подходящие и не очень места. Как-то раз я уже показывал свою коллекцию Arduino-совместимых плат, и с тех пор она только росла и ширилась. Теперь в ней случилось особенное пополнение: русская (пока не) народная «Ардуина» ELBEAR от сибирской компании «Элрон» на базе отечественного микроконтроллера MIK32 «Амур», о существовании которой я узнал несколько дней назад из статьи на Хабре . В статье я изложу частный опыт искушённого любителя, который пытается импортозаместить зарубежную Arduino и приспособить данную плату для своих любительских нужд, не залезая в дебри. Конечно, это далеко не первая подобная публикация, с поездкой на поезде хайпа я припозднился примерно на годик. Зато она отражает актуальное положение дел и демонстрирует, чем чреват смелый прыжок веры прямо в неизвестность без предварительного изучения вопроса. К тому же, я не самый обычный ардуинщик. Вкусы мои специфичны: я не сделал ни одной метеостанции, мой дом глуп как пробка, и даже мои часы на Arduino — стрелочные. Вместо этого я делаю вещи, так или иначе связанные с электронными и видеоиграми, демосценой, звуком и музыкой с уклоном в ретро. И разнообразные ардуины мне нужны и интересны именно в этом контексте. А значит, есть шанс, что будет интересно.

habr.com/ru/companies/ruvds/ar

#ruvds_статьи #arduino #arduino_nano #arduino_uno #arduino_ide #ардуина #микроконтроллеры #микроэлектроника #ws2812 #adafruit #амур #мик32_амур #mik32_amur #amur #К1948ВК018 #микрон #элрон #ELBEAR #ELBEAR_ACEUNO #ELBEAR_ACENANO #AY38910 #ST7789 #SH1106 #ILI9488 #ili9341 #импортозамещение

Steve Pomeroy

My BFF wanted to have some light-up eyes for a costume that she's making, specifically ones that would react when she spoke. So I made her this little assembly, which holds some round LED boards a nice distance away from some LED black acrylic. I'm driving them with WLED running on an Adafruit Mini Sparkle Motion board so it can be powered off a battery pack. The built-in mic means she can have her voice-reactive eyes too!

printables.com/model/1320889-l

#wled #Adafruit #costuming

LeRoy Miller

Here is another sketch running, turns out the font not upside down, just flipped and I'm starting to wonder if it is a weird quarky display panel - like the panel is backward, and it's not really a problem of the library.

Thou, Adruino_GFX library seems to be fine using this display.... maybe I should just use that library.

#Arduino #ESP32S3 #ArduinoGFX #Adafruit

LeRoy Miller

This is a Wemos ESP32-S3 pro mini board, it has a 0.85" 128x128 #GC9A01 LCD, and I'm using an #Adafruit Library - which seems to work very well - except when it comes to displaying text.....
It's like the #font is render flipped and upside down, has anyone seen this before - how would you go about fixing it?

#ESP32S3

Habr

E-paper Arduino термометр на ESP-IDF

Наверное каждый любитель электроники имеет в запасе модули приобретенные на всякий случай. Так несколько лет назад я не смог пройти мимо 1.5 дюймового E-Ink дисплея, лежащего на витрине радиомагазина. Через некоторое время нашлось для него применение. В статье ESP32 E-Paper Thermometer описывается, как отображать окружающую температуру, измеренную с помощью датчика DS18B20. Проект выполнен в Arduino IDE. Но я решил пройти "Путь самурая" и портировать код на ESP-IDF. Пришлось немного повозится с библиотеками для работы с дисплеем. На этом мой путь не окончился, как говорят: "У самурая нет цели, есть только путь". И я решил, что было бы неплохо добавить еще несколько сенсоров, измеряющих влажность, давление, CO2, а потом отправлять эти данные по MQTT. В том же радиомагазине был приобретен фанерный домик-конструктор со светодиодным ночником. А в другом магазине - модуль с датчиками. Таким образом родилась идея сконструировать Micro-smart-home. На передней части домика расположен дисплей на пластиковых стойках. А с другой стороны расположен модуль с сенсорами.

habr.com/ru/articles/912324/

#esp32 #espidf #Arduino #adafruit #ds18b20 #CCS811 #BMP280 #Si7021 #eink

E-paper Arduino термометр на ESP-IDF

Наверное каждый любитель электроники имеет в запасе…

Хабр
adafruit

Got tariff questions? 🌍🚢 Join us TONIGHT on ASK AN ENGINEER at 8PM ET with Ladyada for TARIFF TALK! We’re diving into pricing, BOMs, reshoring, and more. Drop your questions now and tune in for answers! youtu.be/fVrmZe67Xcs

#adafruit #tarifftalk #askanengineer #tariffs

Steve DeGroof 📚🛸

Making an enclosure for my project (thermal camera with video overlay). I couldn't find STL files for a couple of the components, so modeled stand-ins. So far, everything fits into the bottom section. Waiting on the top section to finish printing.
#3dDesign #3dPrinting #Arduino #Adafruit

Muro deGrizeco

@adafruit

Silly question:

Would Adafruit consider making a product like the ClockworkPi PicoCalc cyberdeck?

Low cost, instant on interpreter, screen and keyboard, runs on rechargable batteries?

Heck, and if I could get a portable old-school mac about 40 years late...

#adafruit #picocalc

Mar 27, 2025, 17:59 · · · 0 · 0
Steve DeGroof 📚🛸

Playing around with a thermal camera and some linear interpolation.
The hardware's a 3 board stack: AMG8833 Thermal Camera on top, #Adafruit RP2040 Feather in the middle, 320x240 Touchscreen on the bottom, all powered by a 3.7V battery pack. #Arduino
youtube.com/watch?v=I_UevwrnZjk

- YouTube

Enjoy the videos and music you love, upload original…

www.youtube.com
Tim 🎮

And done. Do you want a simple breakout board for #Adafruit's ADA504 5-way navigation switch (it clicks in four directions, and straight down in the middle)? You can download the Gerber files for one here, and get a few of them made for yourself at Oshpark, JLCPCB etc for a few bucks: github.com/timixretroplays/sim

Do you want one and happen to be in Australia? DM me and I'll post you one of mine.

#Arduino #Electronics #SimpleBreakouts

Stylus

Just playing Super Mario All Stars on an RGB matrix panel as you do.

To keep things together better, I 3D printed a bracket in two pieces, the subject of a work in progress playground note: adafruit-playground.com/u/jepl

This is using a 3rd party breakout board with 3 HUB75 connectors. I recently added the ability to drive up to 3 connectors to Adafruit Piomatter, as well as temporal dithering.

In this specific interest, I'm using 2 connectors to drive a total of 4 64x64 panels. --num-planes=6 --num-temporal-planes=2 means I'm getting effective 18 bit color, albeit with the least significant 2 bits being shown on alternate refreshes, creating a tiny amount of 44Hz color shimmer.

All these "go faster" tricks together give me about 88Hz refresh rate on the panel, despite that we're still limited to about 10MB/s of data between the PI's main CPU and the PIO peripheral that's acting as the LED controller.

#Adafruit #RaspberryPi #Pi5 #HUB75 #LEDs
