I did some experiments measuring propagation delay in a simple chain of 3 digital inverters (NOT gates) (74LS04).

I'm honestly not sure my entry-level scope is fast enough to accurately measure this, but it's fun to try.

It's also interesting to watch the signals completely freak out when you change the input voltage too slowly, but I didn't make a screenshot of that.
