Lup Yuen Lee 李立源 @lupyuen@qoto.org

What's inside #PineDio #LoRa Gateway

https://lupyuen.github.io/articles/gateway?3#inside-pinedio-gateway

Hope to see #PineDio #LoRa Gateways everywhere ... Schools, Workplaces and Homes! 👍

https://lupyuen.github.io/articles/gateway?2

#PineDio Gateway shows slightly weaker Signal Strength (RSSI) for received #LoRa Packets ... Maybe due to antenna? 🤔

https://wiki.pine64.org/wiki/Pinedio#Gateway

Let's benchmark the two #LoRa Gateways: 1️⃣ RAKwireless WisGate RAK7248 2️⃣ #PineDio Gateway

https://wiki.pine64.org/wiki/Pinedio#Gateway

#PineDio Gateway now forwarding #LoRa Messages from Nearby Devices to #TheThingsNetwork 🎉

https://lupyuen.github.io/articles/ttn#add-gateway-to-the-things-network

#PineDio #LoRa Gateway is now Alive ... In #TheThingsNetwork! 🎉

https://lupyuen.github.io/articles/ttn#add-gateway-to-the-things-network

But first we run "gateway-version" to fetch the #LoRa Gateway ID from #PineDio Gateway

https://lupyuen.github.io/articles/ttn#add-gateway-to-the-things-network

Select the #LoRa Frequency for #PineDio Gateway in gateway-config

https://www.thethingsnetwork.org/docs/lorawan/frequencies-by-country/

Flash @RTP's awesome all-in-one Armbian image to a microSD Card ... Boot it on #PineDio #LoRa Gateway ... ChirpStack and #TheThingsNetwork Packet Forwarder are up!

https://www.buymeacoffee.com/politictech/pinedio-armbian-image-chirpstack-ttn

What's inside #PineDio LoRa Gateway? 1️⃣ PINE A64-LTS Arm64 SBC 2️⃣ RAKwireless RAK2287 #LoRa Module with Semtech SX1302 Concentrator

https://wiki.pine64.org/wiki/Pinedio#Gateway

We're on the pre-production #PineDio #LoRa Gateway @PINE64 ... But soon I hope we'll see PineDio Gateway everywhere: Schools, Workplaces and Homes!

https://wiki.pine64.org/wiki/Pinedio#Gateway

Many thanks to @RTP for creating the awesome all-in-one Armbian image for #PineDio #LoRa Gateway! 🙏

https://www.buymeacoffee.com/politictech/pinedio-armbian-image-chirpstack-ttn

Let's connect #PineDio #LoRa Gateway @PINE64 to #TheThingsNetwork

https://wiki.pine64.org/wiki/Pinedio#Gateway

#PineDio #LoRa Gateway: Armbian Image with ChirpStack and The Things Network

https://www.buymeacoffee.com/politictech/pinedio-armbian-image-chirpstack-ttn

Our #BL602 Articles on #LoRa and LoRaWAN have been updated with the new repos

https://github.com/lupyuen/lupyuen.github.io/commit/4473fa2cb9ca82a5df3ee70c52a9083c4b036eba

#PineDio Stack #BL604 now uses the same #LoRa SX1262 Driver as PineDio USB! 🎉

https://github.com/lupyuen/bl_iot_sdk/commit/caae2d5219700df297411641be7286ada07f7804?diff=unified

Why won't the #LoRa Backplate respond to "i2cdetect" on #PinePhone? 🤔

https://github.com/lupyuen/pinephone-lora#test-lora-backplate-on-pinephone

How the #LoRa SX1262 Driver receives a LoRa Message

https://lupyuen.github.io/articles/usb?90#receive-done

What happens inside #LoRa SX1262 Driver ... When we transmit a LoRa Message

https://lupyuen.github.io/articles/usb?89#radiosend-transmit-message

Documenting the Internals of the #LoRa SX1262 Driver ... So it's easier to maintain for #PineDio Stack BL604 and PineDio USB Dongle

https://lupyuen.github.io/articles/usb?88#appendix-radio-functions
