Lup Yuen Lee 李立源 @lupyuen@qoto.org

#PineCone #BL602 In A Box

Remapped JTAG Pins for #PineCone #BL602

https://github.com/lupyuen/bl_iot_sdk/releases/tag/v0.0.1

#PineCone #BL602's Brilliant LED @ThePine64 ... After remapping the #RISCV JTAG Pins

https://github.com/lupyuen/bl_iot_sdk/releases/tag/v0.0.1

Remapping the JTAG Port for #PineCone #BL602

https://github.com/lupyuen/bl_iot_sdk/releases/tag/v0.0.1

Is #PineCone #BL602 based on SiFive E21 #RISCV Core ... Instead of SiFive E24? 🤔

https://github.com/pine64/bl_iot_sdk/blob/master/components/bl602/bl602_std/bl602_std/StdDriver/Inc/bl602_gpio.h#L98

Nope #PineCone #BL602 JTAG Port doesn't respond ... Perhaps because the JTAG pins are connected to the onboard LED? No more #RISCV JTAG Party tonight @PINE64 🙁

https://lupyuen.github.io/articles/pinecone

#PineCone #BL602 LED is connected to the same pins as the JTAG port 🤔

https://github.com/pine64/bl602-docs/blob/main/mirrored/Pine64%20BL602%20EVB%20Schematic%20ver%201.1.pdf

Testing #RISCV #RustLang on #PineCone #BL602 @PINE64

https://github.com/lupyuen/bl602-rust-guide/blob/main/README.md

#PineCone #BL602 all dressed for the #RISCV JTAG Party tonight

https://lupyuen.github.io/articles/pinecone

#DuckDuckGo vs #Google ... Duck picked up something useful that Google missed! 0x20000c05 is the JTAG ID for BL602

Headers soldered on #PineCone #BL602 @PINE64 ... #RISCV JTAG port exposed ... Ready to test JTAG Debugging!

https://lupyuen.github.io/articles/pinecone

@PINE64 Better now ... Except for the melted jumper

Soldering headers onto #PineCone #BL602 @PINE64 😱 ... Yep that's a Laptop Stand on an Ironing Board

https://lupyuen.github.io/articles/pinecone

#JTAG Port for #PineCone #BL602 @PINE64 ... Time to solder the headers 😱

https://lupyuen.github.io/articles/pinecone

Schematics for #PineCone #BL602 @PINE64

https://github.com/pine64/bl602-docs/tree/main/mirrored

Jumper goes to the H ... Only when flashing #PineCone #BL602 @PINE64

https://lupyuen.github.io/articles/pinecone

Kitchen Studio

Kitchen Studio for #PineCone #BL602

Last Light in #Singapore

How to flash #RISCV Firmware to #PineCone #BL602 @ThePine64

https://lupyuen.github.io/articles/pinecone
